REEVUE MEDICAL METABOLIC RATE ANALYSIS SYSTEM

The REEVUE® measures the oxygen that the body consumes. Using this measurement it calculates a patient’s Resting Energy Expenditure (REE), commonly referred to as a Resting Metabolic Rate (RMR). Dietitians can screen for abnormally low metabolic rates and pinpoint the precise caloric intake required for weight loss, maintenance, or weight gain.

Direct Oxygen Measurement

ReeVue® by KORR directly measures the concentration of oxygen breathed out by each patient. The patient merely breathes through a simple mouthpiece as all the exhaled air is collected and analyzed. Because there is a direct correlation between oxygen consumed and calories burned (4.813 calories for every milliliter of oxygen consumed), an accurate measurement of oxygen consumption is an effective measurement of calorie consumption.

Pre-test Requirements

It is desirable to measure a person’s metabolic rate at a true resting level. To ensure one is at rest, we recommend the following preparation:

  1. Avoid eating a meal 4 hours before the test.
  2. Avoid exercising on the day of testing.
  3. If possible, avoid the use of stimulants such as caffeine prior to testing.
  4. During the test it will be important to get into a comfortable position and relax as much as possible.
  5. Keep lips sealed lightly around the mouthpiece. It is important that all the air breathed out is analyzed by your KORR® machine.

Conduct a Test

  1. Turn on your KORR® machine and wait while it automatically calibrates. The machine will indicate when calibration is complete. It is important that no hose or filter be attached during calibration.
  2. Expand the MetaBreather® hose to its full length (5 feet) and connect it to the machine. Be sure to use only a KORR® manufactured MetaBreather®, as use of any other breathing device will not insure accuracy and will void your KORR® factory warranty.
  3. Have the patient place the nose clip on his nose and the mouthpiece in his mouth, using his lips to seal around the edges. The patient should be relaxed and breathe normally.
  4. After approximately 10 minutes, the machine will end the test and prompt the tester to enter in patient data to compare patient results to averages. The results can then be printed out.
